| Feature | Performance Benefit |
|---|---|
| Ultra-low no-load loss | Only ~1/5 of silicon steel cores, reduces long-term energy costs |
| High saturation flux density (~1.56T) | Enables smaller, lighter component designs |
| Wide frequency range | Suitable for 50Hz distribution to high-frequency power electronics |
| Low noise & low magnetostriction | Ensures quiet, stable operation in sensitive environments |
| Process Type | Description | Best For |
|---|---|---|
| Non-Annealed | Raw wound core, no heat treatment | Low-cost, non-critical applications with basic magnetic performance needs |
| Annealed | Precision heat-treated to optimize magnetic properties | Standard transformers, inductors requiring stable permeability and low loss |
| Epoxy Coated | Encapsulated with epoxy resin for insulation & mechanical protection | Harsh environments, high humidity, or vibration-prone installations |
| With Housing (Cased) | Pre-assembled in plastic/metal enclosures, ready for direct use | Fast integration into modules, common-mode chokes, and compact power supplies |
| Parameter | Typical Value |
|---|---|
| Material | Fe-based amorphous alloy (1K101 grade) |
| Ribbon Thickness | 25µm (standard) |
| Saturation Flux Density (Bs) | 1.56–1.59 T |
| Core Loss (Pcv) | ≤0.2 W/kg @ 50Hz, 1.3T |
| Operating Temperature | -40°C ~ +130°C |
| Available Shapes | Toroidal, rectangular, C-core, oval, custom profiles |
6. Get in Touch
Drop us a message to discuss your specifications!
Our Iron-Based Amorphous Alloy Cores are made from ultra-thin amorphous ribbons (20–30µm) via precision winding and optional post-processing. Compared with traditional grain-oriented silicon steel cores, they feature ultra-low core loss, high magnetic permeability, and compact size — ideal for energy-efficient power systems.
Our Iron-Based Amorphous Alloy Cores are made from ultra-thin amorphous ribbons (20–30µm) via precision winding and optional post-processing. Compared with traditional grain-oriented silicon steel cores, they feature ultra-low core loss, high magnetic permeability, and compact size — ideal for energy-efficient power systems.
